Made for Heat

L&L Thermal

Made for Heat

L&L의 열 관리 솔루션은 엔진을 보호하고, 효율적으로 작동하도록 하여 차량 운행이 환경에 미치는 영향을 제한합니다.

L&L Thermal고객 맞춤형 제품을 통한 최적화된 단열성능.

전 세계 대부분의 국가는 운송 수단이 환경에 미치는 영향을 제한하는 방법을 지속적으로 모색하고 있습니다. 내연기관 엔진을 사용하는 차량이 배기가스와 연료 소비를 줄이기 위해서는 엔진을 훨씬 높은 온도에서 작동시켜야 합니다. L&L Products는 이러한 높은 온도에서 작동하는 엔진을 위한 열 관리 솔루션을 제공합니다.



연락주세요!

열 관리 솔루션에 관심이 있으신가요? 대화를 기다리고 있습니다!

연락처

EFS™ Thermal Solutions​

EFS™ Thermal solutions 은 엔진을 보호하고 효율적으로 유지하여 배기가스와 연료 소비를 줄이는 데 도움을 줍니다. 이러한 솔루션은 엔진 소음 감소에도 도움이 됩니다.



Battery Thermal Insulation

소개

Outside influences like adverse exterior temperatures mean that active thermal management systems must consume a substantial amount of energy to ensure optimal battery temperatures. Our Battery Thermal Insulation protects the battery from such a harsh environment and improves the range of the battery-powered vehicle.​

Battery Thermal Insulation comprises three to six layers, based on the application and flammability requirements (UL94 V0/Non-Combustible). ​

Key Attributes

  • Maintains battery temperature for optimal battery efficiency and life​
  • Available as flat-cut and 3D thermoformed parts​
  • Can be installed using current installation process i.e. pressure adhesives / mechanical studs ​

Benefits

  • 뛰어난내열성
  • 불연성
  • 비신축성
  • 무독성
  • 그리스, , 진흙에대한뛰어난내화학성

Applications

EFS Battery Thermal Insulation

EFS Battery Thermal Insulation

  • 최적의 배터리 수명과 효율성을 위해 배터리 온도를 유지하는 패시브 배터리 단열(최대 70 °C)을 통해 배터리 수명을 최적화합니다.

더 알아보기

Engine Bay Heat and Noise Shields​

About

The regulations for noise emissions from the engine towards its surroundings are becoming more stringent each year. The target is to reduce noise emitted by transportation. Reducing engine bay noise at the source also means a cost reduction for cities, as they no longer need to install noise management walls.​

Managing both heat and noise is a specialty of L&L Products. Our Engine Bay Heat and Noise Shields comprise three to six layers, based on customers’ application needs in terms of noise reduction, heat and flammability requirements (e.g. UL94 V0/Non-Combustible). Outside of the target performance, Engine Bay Heat and Noise Shields offer excellent resistance against chemicals, cleaning agents, grease, water, stone chip, and mud and can be cleaned by a power wash.​

Key Attributes

  • Comprises three to six layers​
  • Parts are available as flat-cut and/or as 3D thermoformed to enable any shape​
  • Can be installed using the customer’s current installation process, i.e. with pressure adhesives and mechanical studs​

Benefits

  • Non-stretchable​
  • Excellent resistance against chemicals, cleaning agents, grease, water, stone chip and mud​
  • Can be cleaned by a power wash​

Applications

EFS Acoustic Firewall Solutions (Inner and Outer)

EFS Acoustic Firewall Solutions (Inner and Outer)

  • Reducing in-cabin noise with a multilayer approach that covers a broad frequency range.

더 알아보기

Resources

Heat Shield​

About

Our Heat Shield is a non-stretchable, high-temperature resistant insulation solution for exhaust thermal management applications. It comprises of three to eight layers depending on the application and functional requirements and is available in both rigid (metallic solution) and flexible casings. Heat Shields demonstrate excellent heat-strength resistance, improved heat / temperature retention, and are non-burning. ​

Our Heat Shield allows OEMs to achieve Euro IV or VI compliance (depending on region) and are non-toxic with excellent chemical resistance against grease, water, and mud.​

Key Attributes

  • 3 to 8 layered constructions (flexible/metallic)​
  • Application temperature ranges from -30°C to +850°C, during continuous exposure at 800°C.​
  • Thermal conductivity, k-value in range of 0.03 to 0.036 w/mk @ 22.5 °C​
  • Delta T across thickness in range of 75 - 85%​
  • Delta T across length 1m to 3m, in range of 3°C to 15°C (depending upon construction & functional requirements)​

Beneifts

  • Improves flex properties versus traditional solutions​
  • Anti-friction and air-pockets to assist in circulation / retention of hot air​
  • Excellent heat strength resistance
  • Non-burning​
  • Non-toxic
  • Excellent chemical resistance against grease, water, and mud​

Applications

EFS Thermal Flexible Heat Shield

EFS Thermal Flexible Heat Shield

  • High temperature capable flexible insulation solution for exhaust thermal management applications.

Generator Sets​

Generator Sets​

  • High temperature zones​

더 알아보기

Under-Hood and Under-Floor Thermal Insulation​

About

As EURO-VI engines generally run at higher temperatures compared to preceding engines, L&L Products engineers a custom insulation solution that works well for under-hood and under-floor applications. Our Under-Hood and Under-Floor Thermal Insulation maintains more of a steady temperature within ambient +2°C (35°F) in the driver’s cabin for best possible driver and passenger comfort.​

Under-Hood and Under-floor Thermal Insulation comprises of four to six layers, based on the application and functional requirements, temperatures from the engine bay / EATS system ranges from 150°C (302°F) to as high as 400°C (750°F) when entering the cab. Parts are available as flat-cut and/or as 3D thermoformed to enable any shape. ​

Key Attributes

  • Comprises of four to six layers​
  • Designed to maintain cabin temperature within ambient +2°C for enhanced driver comfort​
  • Available as flat-cut and 3D thermoformed parts​
  • Can be installed using current installation process i.e. pressure adhesives / mechanical studs ​

Benefits

  • Excellent heat strength resistant
  • Non-burning​
  • Non-stretchable​
  • Non-toxic​
  • Excellent chemical resistance against grease, water, and mud​

Applications

EFS Thermal Engine Compartment Insulators

EFS Thermal Engine Compartment Insulators

  • High-temperature capable insulation solution for under hood and under floor applications.

더 알아보기

Resources
